Detailed explanation of the structure and characteristics of the double shaft shredder
The dual-shaft shredder can be automatically controlled by a microcomputer (PC) according to customer requirements. It is equipped with start, stop, reverse and overload automatic reverse control functions. It has the characteristics of low speed, high torque and low noise. The bearing seat adopts a split type. , easy to disassemble and replace the knife. The dual-shaft shredder produced by SUNY GROUP adopts a dual-shaft structure to achieve two-shaft extrusion and shredding. Its applications include: plastic beverage cans, plastic barrels, iron barrels, packaging boxes, PE pipes, wooden pallets, plastic pallets, TV sets, washing machines, refrigerator casings, tires, copper, aluminum, lead, and steel plates with a thickness of less than 5mm, etc. .
Double shaft shredder structure:
1. Crusher main body
The main body of the equipment is welded with high-quality steel plates for stress relief treatment/overall machining to ensure the stability of the equipment under heavy loads for a long time.
2. Bearings/seals
The bearing seat adopts the splicing and disassembling type, which can quickly remove the moving knife, fixed knife, bearing and other components, and is easy to maintain and replace the tool. The unique sealing structure effectively blocks the contact of broken objects and grease, and can also protect the bearing and the bearing when handling liquid materials. gear etc.
3. Moving knife/fixed knife
The moving knife material is made of special alloy tool steel forging blank, precision machining, multiple heat treatment and low temperature freezing heat treatment technology. The fixed knife is installed by hook, which optimizes the tool replacement function and makes the tool maintenance and replacement more efficient.
4. Tool shaft
High-strength and heavy-duty special steel is used for processing and refining, and it is more reasonable to cooperate with the tool to provide powerful power for cutting.
Working characteristics of double shaft shredder:
1: In actual production, the dual-shaft shredder has low noise, lower energy consumption than other shredders, and the characteristics of high output fully reflect the advantages of low-speed and large-torque shearing design.
2: There are heavy moving knives inside the machine, the crushing efficiency is much improved, and the knives are all cast with alloy steel, which is stronger in daily use and will increase the service life a lot.
3: The main frame plate is thicker than the initial machine, which can resist high torque and is stronger in actual production.
4: The double-shaft shredder has the characteristics of low speed and low noise, which is more prominent in environmental protection conditions.
The above is the relevant introduction to the double-shaft shredder. Generally, the choice of the double-shaft shredder needs to be combined with the customer's material, output, and other requirements. In order to meet the needs of the customer, SUNY GROUP can customize the production according to the customer's processing materials. , ranging from micro, small, medium to large models can be manufactured. In addition, each customer can go to the factory or live video to check the test effect. At the same time, there is also a professional technical after-sales team to solve various problems encountered in the later use.
